LiGuVCY Hydraulic Directional Double Acting Control Monoblock Valve, 6 Spool 11GPM SAE Ports 2 Joystick Hydraulic…

Hydraulic Directional Double Acting Control Monoblock Valve, 6 Spool 11GPM SAE Ports 2 Joystick Hydraulic Directional Control Valve 3625 PSI Fit for Small Tractors Loaders Etc

Specification:
Double acting hydraulic valve
Spool count: 6 Spool
Flow Rating: 11 GPM (40 l/min)
Max Operating Pressure: P=3625 PSI, T=725 PSI, A&B=4350 PSI
A&B Work Ports: 8 SAE O-Ring (3/4″-16) Thread
Inlet Port: 10 SAE O-Ring (7/8″-14) Thread
Outlet Port: 10 SAE O-Ring (7/8″-14) Thread
Relief valve: Adjustable

Features:
– The hydraulic directional control valve is of high tensile strength cast iron monolithic construction
– Durable for long service life, stable and reliable performance
– The 6 spools 11GPM hydraulic control valve has the characteristics of small volume, large flow and stable operation
– Come with 6 spools and SAE O-ring in/out ports
– The hydraulic directional control valve has a relief valve range of up to 3625 PSI and a maximum flow of 11GPM
– Hydraulic directional control valve is used in agricultural machines tractors sprayers construction machines loaders excavators etc

Package Includes:
1 x 6 Spool 11GPM Double acting hydraulic directional control valve

Make sure this fits by entering your model number.
Durable Quality – The hydraulic directional control valve is of high tensile strength cast iron monolithic construction, durable for long service life, stable and reliable performance.
Peculiarity – Equipped with 2 Joystick 6 spools 11 GPM hydraulic control valve has the characteristics of small volume, large flow and stable operation. Come with 6 spools and SAE O-ring in/out ports.
Inner Check – Hydraulic control valves are used to operate double acting cylinders. All standard spools are spring-returned and can be reset to the neutral position. The check valve inside the valve body is to ensure the hydraulic oil not to be returned.
High Performance – The hydraulic directional control valve has a relief valve range of up to 3625 PSI and a maximum flow of 11 GPM.
Wide Application – Hydraulic directional control valve is used in agricultural machines tractors sprayers construction machines loaders excavators etc.
